UBO~2T Ball Nose End Mills
-
Carbide
Super MG -
Grain Size
0.4μm -
Helix Angle
5° -
Flutes
2 -
HRC
65 -
Coating
x
TiaLN -
Flute Edge
Ball -
Flute Edge
Clearance
| Type No. | Diameter | Flute Length | Effective Length | O.A.L. | Shank Dia |
|---|---|---|---|---|---|
| D1 | L1 | L2 | L3 | D2 | |
| UBO~0102 | R0.5 | 1 | 3 | 50 | 4 |
| UBO~0152 | R0.75 | 2 | 5 | 50 | 4 |
| UBO~0202 | R1 | 3 | 6 | 50 | 6 |
| UBO~0302 | R1.5 | 4 | 8 | 50 | 4 |
| UBO~0402 | R2 | 5 | 10 | 50 | 4 |
| UBO~0602 | R3 | 6 | 12 | 50 | 6 |
| UBO~0802 | R4 | 8 | 16 | 60 | 8 |
| UBO~0302L | R1.5 | 4 | 8 | 75 | 6 |
| UBO~0402L | R2 | 5 | 10 | 75 | 6 |
| UBO~0602M | R3 | 6 | 12 | 75 | 6 |
| UBO~0602L | R3 | 6 | 16 | 100 | 6 |
| UBM~0802L | R4 | 8 | 25 | 100 | 8 |
| UBM~1002L | R5 | 10 | 30 | 100 | 10 |
