Products

SEA~2T Square End Mills

  1. Carbide
    NaNo
    Super MG

  2. Grain Size
    2μm

  3. Helix Angle
    35°

  4. Flutes
    2

  5. HRC
    65

  6. Coating
    TixSiN

  7. Flute Edge
    Square

Type No. Diameter Flute Length O.A.L. Shank Dia
  D1 L1 L3 D2
SEA~0102 1 3 50 4
SEA~0152 1.5 4 50 4
SEA~0202 2 6 50 4
SEA~0252 2.5 8 50 4
SEA~0302 3 8 50 4
SEA~0352 3.5 10 50 4
SEA~0402 4 11 50 4
SEA~0502 5 13 50 6
SEA~0602 6 16 50 6
SEA~0702 7 16 60 8
SEA~0802 8 20 60 8
SEA~1002 10 25 75 10
SEA~1202 12 30 75 12
SEA~1602 16 40 100 16
SEA~2002 20 45 100 20

List of recommended milling conditions

Read PDF
