Carbide Tools - Janpo Precision Tools Co., Ltd.

XRT-2T Corner Radius End Mills

Type No.	Diameter	Corner R	Flute Length	O.A.L.	Shank Dia
	D1	r	L1	L3	D2
XRT~01012	1	0.1	3	50	4
XRT~01022	1	0.2	3	50	4
XRT~01032	1	0.3	3	50	4
XRT~01522	1.5	0.2	4	50	4
XRT~01532	1.5	0.3	4	50	4
XRT~02022	2	0.2	6	50	4
XRT~02032	2	0.3	6	50	4
XRT~02052	2	0.5	6	50	4
XRT~02522	2.5	0.2	8	50	4
XRT~03022	3	0.2	8	50	4
XRT~03032	3	0.3	8	50	4
XRT~03052	3	0.5	8	50	4
XRT~03102	3	1	8	50	4
XRT~04022	4	0.2	10	50	4
XRT~04032	4	0.3	10	50	4
XRT~04052	4	0.5	10	50	4
XRT~04102	4	1	10	50	4
XRT~04152	4	1.5	10	50	4
XRT~05022	5	0.2	13	50	6
XRT~05032	5	0.3	13	50	6
XRT~05052	5	0.5	13	50	6
XRT~05102	5	1	13	50	6
XRT~06022	6	0.2	15	50	2
XRT~06032	6	0.3	15	50	2
XRT~06052	6	0.5	15	50	2
XRT~06102	6	1	15	50	2
XRT~06152	6	1.5	15	50	2
XRT~06202	6	2	15	50	2
XRT~08032	8	0.3	20	50	8
XRT~08052	8	0.5	20	50	8
XRT~08102	8	1	20	50	8
XRT~08152	8	1.5	20	50	8
XRT~08202	8	2	20	50	8
XRT~08252	8	2.5	20	50	8
XRT~08302	8	3	20	50	8
XRT~10032	10	0.3	35	50	10
XRT~10052	10	0.5	35	50	10
XRT~10102	10	1	35	50	10
XRT~10152	10	1.5	35	50	10
XRT~10202	10	2	35	50	10
XRT~10252	10	2.5	35	50	10
XRT~10302	10	3	35	50	10
XRT~12032	12	0.3	30	50	12
XRT~12052	12	0.5	30	50	12
XRT~12102	12	1	30	50	12
XRT~12152	12	1.5	30	50	12
XRT~12202	12	2	30	50	12
XRT~12252	12	2.5	30	50	12
XRT~12302	12	3	30	50	12
